13Ton Round Type American Axle
More than 20 years of experience (since 2005)
Implementation of ISO 9001-2015
Quality tested by an independent laboratory
Warranty: 12 months from date of shipment
Fatigue life: 1,700,000 cycles
Bearing position machining accuracy (diameter): 0~0.025mm 0~0.025mm
Brake shoe: cylindrical grinding
Simultaneous machining of both ends of the crossbeam
We provide fuwa 13 ton round and square axle, fuwa 16 ton axles, and the raw materials come from China's top 3 steel.
An American axle typically refers to an axle assembly that is commonly used in trucks, trailers, and other heavy-duty vehicles.
If you are looking for specific details about a 13-ton round type American axle, it is important to note that axles are rated based on their load-carrying capacity. In this case, a 13-ton axle would be capable of supporting a maximum load of 13 tons.
Product parameters:
Axle Type | Max Capacity | Track | Brake | CentreDistance | Axle Beam(mm) | Centre Distance | Wheel Fixing | Recom | (kg) Axle Weight | Note | |||
Stud | D1P.C.D | D2 Hole Diameter | Total Length | ||||||||||
XH-10.5 | 12 | 1820 | 420*180 | ≥950 | o127 | 368 | 10*M22*1.5 | 285.75 | 221 | ~2165 | 7.5V-20 | 360 | Bearing(Inner)HM518445/10 |
XH-10.5 | 12 | 1820 | 420*180 | ≥950 | o127 | 368 | 10*M22*1.5 | 335 | 281 | ~2165 | 7.5V-20 | 363 | |
XH-13 | 13 | 1840 | 420*180 | ≥930 | 150*150 | 388 | 10*M22*1.5 | 285.75 | 281 | ~2185 | 7.5V-20 | 363 | Bearing(Inner)HM518445/10 |
XH-13 | 13 | 1840 | 420*180 | ≥930 | 150*150 | 388 | 10*M22*1.5 | 335 | 281 | ~2185 | 7.5V-20 | 370 | |
XH-15 | 15 | 1850 | 420*180 | ≥940 | 150*150 | 396 | 10*M22*1.5 | 335 | 281 | ~2185 | 8.0V-20 | 398 | Bearing(Inner)HM220149/10 |
XH-16 | 16 | 1850 | 420*220 | ≥940 | o127 | 354 | 10*M22*1.5 | 335 | 281 | ~2185 | 8.00V-20 | 423 | |
XH-16 | 16 | 1850 | 420*220 | ≥940 | 150*150 | 354 | 10*M22*1.5 | 335 | 281 | ~2205 | 8.00V-20 | 425 | |
Application:
13-ton round type American axle is typically used in heavy-duty vehicles such as trucks, trailers, and specialty vehicles that require a high load-carrying capacity. This type of axle is designed to withstand heavy loads and provide stability and durability for the vehicle it is installed in.
Some common applications for a 13-ton round type American axle include:
Heavy-duty trucks: Used in commercial trucks for transporting goods over long distances.
Trailers: Installed on trailers used for transporting heavy equipment, construction materials, or other large items.
Specialty vehicles: Used in vehicles such as dump trucks, tanker trucks, and utility vehicles that require a high load capacity.
These axles are crucial components in ensuring the safe and efficient operation of heavy-duty vehicles, providing the necessary support and stability for carrying heavy loads. If you have a specific application in mind or need further information, please let me know so I can provide more tailored assistance.
FAQ
Q1: Does your company is a factory or trade company?
A1: We have a factory ourself, we are on this business for many years in China.
Q2: Whats the qualify assurance we provided and how do we control quality?
A2: Our products have passed ISO9001 international quality standard certification. We implement all-round quality control from raw materials to finished products. The quality inspection system tracks the whole process and matches the extreme performance test of finished products to fully guarantee the product quality.
Q3: What's your MOQ?
A3: Can be negotiated
Q4.What can you buy from us?
A4:Trailer Axle,Trailer Mechanical Suspension,Semi Trailer Spare Parts.
